Monitoring Kubernetes Cluster using OpenTelemetry Components
Don’t forget to share!
Introduction to Kubernetes Monitoring with OpenTelemetry
How do you keep an eye on an ever-growing digital landscape without losing sight of what matters? Kubernetes has changed the way we deploy and manage containerized applications and set a new bar for efficiency and scalability. But with great power comes great responsibility in the form of ‘monitoring’. As your clusters grow, monitoring everything on it can get overwhelming and hard to aggregate. That’s where the K8s Cluster Receiver comes in as a way to aggregate all the important cluster-level metrics and events. By using OpenTelemetry you can standardize your telemetry data collection and see the full picture of how your cluster is running in real-time for both efficiency and correctness.
What is OpenTelemetry?
Definition and Goals
OpenTelemetry is an open-source tool for producing and combining telemetry (metrics, logs, and traces) across diverse technologies and platforms, making observability simple to integrate and deploy.
Components of OpenTelemetry
OpenTelemetry has the following components:
- APIs: Instrumentation interfaces
- SDKs: Telemetry data collectors
- Libraries: Instrumentation for specific languages
- Integrations: Built-in components for common libraries and frameworks
What is an OpenTelemetry Collector
This component facilitates the exporting, processing, and aggregating of telemetry data and offers extreme flexibility and compatibility in different operational modes.
Now that you have a good grasp on what OpenTelemetry is and its components, let’s move on to getting it up and running in your Kubernetes cluster.
Installing and Configuring OpenTelemetry to Monitor a Kubernetes Cluster
Requirements
To install OpenTelemetry on a Kubernetes cluster, you should already have:
- Kubernetes cluster running
- Kubectl (command-line tool for Kubernetes operations) configured for your cluster
- Helm (package manager for Kubernetes) installed
Installing and Configuring OpenTelemetry Collector
The OpenTelemetry Collector can be installed with Helm charts. The following example simplifies the installation procedure:
helm repo add open-telemetry https://open-telemetry.github.io/opentelemetry-helm-charts helm install my-opentelemetry-collector open-telemetry/opentelemetry-collector
Daemonset vs. Deployment Installations
- Daemonset: Runs a collector on each node in the cluster. This should be used if you want to collect data from each node in the cluster.
- Deployment: Runs a user-defined amount of collectors. This should be used if you want to aggregate data from the collectors on a cluster level.
Now that you know how to install the OpenTelemetry Collector, let's dive into some key components that will boost your Kubernetes monitoring.
Main OpenTelemetry for Kubernetes Components
1. Kubernetes Attributes Processor
The Kubernetes Attributes Processor adds Kubernetes-related metadata to the telemetry data, like pod name, pod namespace, pod labels, etc. This provides better context to the data collected for later analysis.
2. Kubeletstats Receiver:
The Kubeletstats Receiver can be thought of as a postman gathering useful stats from the Kubelet API server. The Kubelet is a component of every node in a Kubernetes cluster and it manages pods and containers. This receiver collects useful metrics regarding CPU utilization, memory usage, etc. directly from the Kubelet. In essence, the Kubeletstats receiver “delivers'' a health report for each of your cluster nodes so that you are aware of how each node is performing.
3. Kubernetes Cluster Receiver
The K8s Cluster Receiver is where cluster-level metrics and events are aggregated. It collects node status, pod conditions, and cluster events so you can see the overall health of the cluster. Use the K8s Cluster Receiver to get visibility into your cluster and fix issues before they turn into bigger problems.
4. Kubernetes Objects Receiver
This receiver collects Kubernetes objects from the API server so you can see the state and changes of Kubernetes resources like deployments, services, and configuration maps.
5. Prometheus Receiver
Prometheus Receiver supports the Prometheus metrics format so you can ingest metrics from applications already instrumented with Prometheus.
6. Host Metrics Receiver
This component scrapes machine-level metrics from nodes so you can see the full system view of resource usage and performance.
7. Filelog Receiver
Filelog Receiver efficiently tails and parses log files so you can monitor and analyze your application logs.
Ready to put it all together? Let's get those OpenTelemetry components deployed and configured.
Deploying and Configuring OpenTelemetry Components
Deployment Guide
Deploying the OpenTelemetry Collector involves setting up either Daemonset or Deployment instances based on your monitoring needs. Here’s an example configuration for deploying a Daemonset:
apiVersion: apps/v1
kind: DaemonSet
metadata:
name: otel-collector
spec:
selector:
matchLabels:
app: otel-collector
template:
metadata:
labels:
app: otel-collector
spec:
containers:
- name: otel-collector
image: otel/opentelemetry-collector:latest
ports:
- containerPort: 55680
protocol: TCP
volumeMounts:
- mountPath: /etc/otel
name: otel-config
volumes:
- name: otel-config
configMap:
name: otel-config
Configuring Key Components
Kubernetes Attributes Processor:
processors:
k8sattributes:
auth_type: serviceAccount
Kubeletstats Receiver:
receivers:
kubeletstats:
endpoint: "https://${KUBELET_HOST}:10250"
auth_type: "kubeConfig"
Best Practices for Kubernetes RBAC
To collect data securely, configure Kubernetes Role-Based Access Control (RBAC) policies. Define roles and bindings that give OpenTelemetry components the required permissions without over-permission.
apiVersion: rbac.authorization.k8s.io/v1 kind: ClusterRole metadata: name: otel-collector-role rules: - apiGroups: [""] resources: ["nodes", "pods"] verbs: ["get", "list", "watch"] --- apiVersion: rbac.authorization.k8s.io/v1 kind: ClusterRoleBinding metadata: name: otel-collector-binding roleRef: apiGroup: rbac.authorization.k8s.io kind: ClusterRole name: otel-collector-role subjects: - kind: ServiceAccount name: otel-collector namespace: default
Creating manifest files
Manifests are required to deploy OpenTelemetry components in your cluster. Manifests define what you want your applications and resources to be. Here’s a manifest for the OpenTelemetry Collector as a Deployment:
apiVersion: apps/v1
kind: Deployment
metadata:
name: otel-collector
spec:
replicas: 3
selector:
matchLabels:
app: otel-collector
template:
metadata:
labels:
app: otel-collector
spec:
containers:
- name: otel-collector
image: otel/opentelemetry-collector:latest
ports:
- containerPort: 55680
protocol: TCP
volumeMounts:
- mountPath: /etc/otel
name: otel-config
volumes:
- name: otel-config
configMap:
name: otel-config
Great job getting everything set up! Now, let's turn to how you can monitor your cluster's performance and health in real time.
Monitoring Cluster Performance and Health
SigNoz Dashboard
SigNoz has a very simple dashboard for visual monitoring and alerting. It integrates with OpenTelemetry to show real-time cluster performance, node conditions, pod phases, and container restarts.
Collecting and analyzing metrics
Collect metrics for node conditions, pod phases, and container restarts to gauge your cluster health. This data can be used to find patterns and predict problems.
Check out ‘Using Prometheus APM Tools for Asset Performance Management’ from OpenObserve for reference.
How to Create Dashboards for Monitoring the Kubernetes Cluster?
Dashboards are essential for monitoring Kubernetes clusters as they provide a human-readable way to interpret the metrics. With OpenTelemetry metrics, traces, and logs, setting up a dashboard is a guided process. Here’s how you can set up dashboards:
- Scope: Start by deciding what metrics you need. Common metrics are CPU usage, memory usage, and I/O operations.
- Use Templates: You can use dashboard templates that can be customized as per your needs.
- Alerts: Make sure your dashboards show current metrics and also forecast potential issues using predictive analysis. Set up alerts for abnormal patterns or when thresholds are crossed.
- Regular Updates: As your cluster changes, so should your dashboards. Update your setups as per the changing needs and metrics of your Kubernetes cluster.
By following these steps you can make sure your Kubernetes monitoring dashboard is complete and up-to-date which is essential for cluster health and performance.
Advanced Monitoring Techniques
- Enhancing Telemetry Data
- Authentication and Security
Secure the Kubernetes API for telemetry by adding authenticating and encrypting data in transit.
- Configure OpenTelemetry
Customize OpenTelemetry to your monitoring needs. This might mean tweaking sampling rates, defining custom metrics, and adding in extra receivers and processors.
Use OpenTelemetry Processors to pull in telemetry data and add context so you can get better insights.
So, what do we do next?
Using OpenTelemetry for Kubernetes cluster monitoring has many benefits, including visibility, resource utilization, and proactive issue resolution. For more information check out the OpenTelemetry and Kubernetes documentation and try out some additional configurations and advanced components of the OpenTelemetry Collector to tune your monitoring.
By using the K8s Cluster Receiver and other OpenTelemetry components you can have full monitoring and your Kubernetes clusters will run smoothly and efficiently. The K8s Cluster Receiver is super useful for high observability, so you can see all the important metrics and events in your cluster.
Further Reading and Resources
Exploring these resources will deepen your understanding of Kubernetes monitoring and OpenTelemetry, enabling you to build more resilient and efficient systems.
