Pipecat → OpenObserve

Updated View MarkdownOpen in ChatGPTOpen in Claude

Capture conversation, turn, and LLM spans with token usage and time to first byte for every Pipecat pipeline. Pipecat is a Python framework for building real-time voice and multimodal AI pipelines. It has built-in OpenTelemetry tracing: point it at an OTLP exporter for OpenObserve and turn tracing on in the PipelineWorker.

Prerequisites

  • Python 3.11+
  • An OpenObserve account (cloud or self-hosted)
  • Your OpenObserve organisation ID and Base64-encoded auth token
  • An OpenAI API key

Installation

pip install "pipecat-ai[openai,tracing]" opentelemetry-exporter-otlp-proto-http python-dotenv

Configuration

Create a .env file in your project root:

OPENAI_API_KEY=your-openai-api-key
OTEL_EXPORTER_OTLP_ENDPOINT=https://api.openobserve.ai/api/your_org_id/v1/traces
OTEL_EXPORTER_OTLP_HEADERS=Authorization=Basic <your_base64_token>

Instrumentation

Call Pipecat's setup_tracing() with an OTLP HTTP exporter once at startup, then create the PipelineWorker with enable_tracing=True. Pipecat creates the spans itself; you do not add manual spans.

The example below runs a text-only pipeline with one LLM call, so it works without a microphone, a speech service, or a transport. In a voice bot, the same two steps add stt and tts spans next to llm in every turn.

from dotenv import load_dotenv
load_dotenv()

import asyncio
import os

from opentelemetry.exporter.otlp.proto.http.trace_exporter import OTLPSpanExporter
from pipecat.frames.frames import EndFrame, LLMContextFrame
from pipecat.pipeline.pipeline import Pipeline
from pipecat.pipeline.worker import PipelineParams, PipelineWorker
from pipecat.processors.aggregators.llm_context import LLMContext
from pipecat.services.openai.llm import OpenAILLMService
from pipecat.utils.tracing.setup import setup_tracing
from pipecat.workers.runner import WorkerRunner

auth_header = os.environ["OTEL_EXPORTER_OTLP_HEADERS"].replace("Authorization=", "")

setup_tracing(
    service_name="pipecat-demo",
    exporter=OTLPSpanExporter(
        endpoint=os.environ["OTEL_EXPORTER_OTLP_ENDPOINT"],
        headers={"Authorization": auth_header},
    ),
)


async def main():
    llm = OpenAILLMService(
        api_key=os.environ["OPENAI_API_KEY"],
        settings=OpenAILLMService.Settings(
            model="gpt-4o-mini",
            system_instruction="You are a helpful assistant. Answer in one sentence.",
        ),
    )

    worker = PipelineWorker(
        Pipeline([llm]),
        params=PipelineParams(enable_metrics=True, enable_usage_metrics=True),
        enable_tracing=True,
        conversation_id="demo-conversation",
    )

    context = LLMContext()
    context.add_message({"role": "user", "content": "Explain distributed tracing."})
    await worker.queue_frames([LLMContextFrame(context), EndFrame()])

    runner = WorkerRunner(handle_sigint=False)
    await runner.add_workers(worker)
    await runner.run()


asyncio.run(main())

setup_tracing() registers a batch span processor, which sends any remaining spans when the process exits. enable_turn_tracking is on by default, so each turn gets its own span.

What Gets Captured

Each conversation produces this span tree:

conversation
└── turn
    ├── stt   (voice pipelines only)
    ├── llm
    └── tts   (voice pipelines only)

OpenObserve stores the dotted attribute names with underscores.

conversation and turn spans

AttributeDescription
conversation_idThe conversation_id you passed, or a generated ID
conversation_typevoice
turn_numberTurn number within the conversation
turn_duration_secondsTurn length in seconds
turn_was_interruptedtrue if the user interrupted the bot

llm span

AttributeDescription
gen_ai_provider_nameProvider (e.g. openai)
gen_ai_request_modelModel requested (e.g. gpt-4o-mini)
gen_ai_operation_namechat
gen_ai_system_instructionsSystem instruction sent to the model
gen_ai_usage_input_tokensInput tokens
gen_ai_usage_output_tokensOutput tokens
inputMessages sent to the model, as JSON
outputText the model returned
metrics_ttfbTime to first byte, in seconds

stt and tts spans carry gen_ai_provider_name and gen_ai_request_model, plus transcript (STT) or voice_id and metrics_character_count (TTS).

Viewing Traces

  1. Log in to OpenObserve and navigate to Traces
  2. Filter by service_name = pipecat-demo to isolate Pipecat spans
  3. Open a trace to see the conversation span with its turn and llm children
  4. Filter by operation_name = llm and sort by duration to find slow model calls
  5. Filter by conversation_id to follow one conversation

Pipecat trace in OpenObserve, Waterfall view of a conversation with turn, stt, llm and tts spans and the llm span attributes

Next Steps

With Pipecat tracing on, every conversation and turn is recorded in OpenObserve. From here you can monitor turn latency and time to first byte, track token usage per conversation, and alert on slow or failed turns.
